The new generation Pan-Tilt Antenna Positioner is designed for high-precision tracking and positioning. Optimized for durability and performance in harsh environments. Supports multiple control protocols and high load capacity.
Advanced motor control algorithms ensure accuracy up to 0.01 degrees for reliable signal tracking.
Constructed with industrial-grade aluminum alloy, IP66 rated for all-weather operation.
Supports RS485, RS232, and Ethernet control interfaces for seamless integration.
Built-in self-test modules can detect faults automatically and report status in real-time.
Modular design allows for quick setup and deployment in various field conditions.
Equipped with the latest generation processing chip for faster response and stability.
| Parameter Category | Technical Specifications |
|---|---|
| Product Name | Pan-Tilt Antenna Positioner (Standard / Enhanced) |
| Model Number | PT-ANT-2024-X1 / PT-ANT-2024-Pro |
| Horizontal Rotation Range | 0° ~ 360° Continuous Rotation |
| Vertical Rotation Range | -45° ~ +90° |
| Rotation Speed | 0.1° ~ 12°/s (Adjustable) |
| Positioning Accuracy | ±0.1° (Optional high precision ±0.05°) |
| Max Load | 30kg / 50kg (Selectable) |
| Input Voltage | DC 24V / AC 220V (Optional) |
| Power Consumption | Max 60W / Static 5W |
| Communication Interface | RS485, RS232, RJ45 Ethernet |
Unlike traditional positioners, our device uses a dual-loop PID algorithm to maintain signal lock even in high-wind conditions.
Engineered with sealed bearings and corrosion-resistant coating, doubling the operational lifespan compared to competitors.
Fully compatible with 99% of antenna types on the market thanks to our universal mounting bracket system.
Ideal for professionals setting up point-to-point microwave links.
Perfect for controlling remote sensing equipment and data collection.
Rapid deployment for emergency response and maritime safety.
Provides stable tracking platforms for anti-drone defense systems.
Carefully open the package and check against the packing list to ensure all accessories are included.
Mount the positioner on a stable bracket or tripod. Ensure screws are tightened to torque specs.
Connect power and control cables according to the wiring diagram. Pay attention to polarity.
Turn on the power supply. The device will perform a self-check. Verify control via software.
The standard model supports up to 30kg, while the enhanced Pro version supports up to 50kg.
Yes, we provide an SDK and support standard Pelco-D/P protocols. Custom protocol integration is available upon request.
We offer a standard 2-year warranty for all parts and labor, with options to extend up to 5 years.
Absolutely. It is IP66 rated, meaning it is dust-tight and protected against powerful water jets.
Standard shipping takes 5-7 business days. Expedited shipping options are available at checkout.
