  • BIT-HS4211
  • BIT-HS4211
  • BIT-HS4211

11 inch Dual Cabin Camera Housing Enclosure

Features of BIT-HS4211 11 inch Outdoor Dual Cabin CCTV Camera Housing & Enclosure


  • 11 inch, indoor/outdoor application

  • Work alone or with pan tilt

  • Aluminum alloy material

  • Top open design, easy camera installation

  • Suitable for short length lens or zoom camera

  • Optional sunshield, heater, fan, wiper

  • IP66 ingress protection


Overview


BIT-HS4211 is a 11'' small size security camera enclosure with dual cabin design for multiple devices protection in all-weather situation. Integrated with internal heater, blower fan and wiper, it provides great protection and working environment for network camera. It is a good choice for night vision video surveillance with extra space for IR LED or laser illuminator.


Technical Specifications


Model

BIT-HS4211

Housing


Application

Outdoor/Indoor

Dimensions
(L)x(W)x(H)

315x216x116 mm
12.40x8.50x4.57 in

Left Cabin Space
(L)x(W)x(H)

170x70x80 mm
6.69x2.76x3.15 in

Right Cabin Space
(L)x(W)x(H)

170x70x80 mm
6.69x2.76x3.15 in

Window

Ø 58mm (2.28 in)

General





Power Supply

AC 24V ± 25%

Power Consumption

≤75W

Working Temperature

-35ºC ~ 60ºC (-31 ºF ~ 140 ºF )

Working Humidity

≤90% RH (No condensing, no heating)

Auto Temperature Control

Heating on: 8ºC(46.4ºF ) ±5, off 20ºC(68ºF ) ±5
Fan on: 37º(98.6ºF )C ±5, off 20ºC(68ºF ) ±5

Protection Level

IP66

Material

Alloy aluminum

Weight

2.5 kg (5.51 lb)






Order Information

Options

Model

Housing Only

Sunshiled

Heater/Fan

Wiper

BIT-HS4211

X

/

/

/

BIT-HS4211K

X

X

/

/

BIT-HS4211SHK

X

X

X

/

BIT-HS4211SHKW

X

X

X

X






Related Products

Model




Pan Tilt

BIT-PT409, BIT-PT410

Wallmount Bracket

BIT-WS2771, BIT-WS1293, BIT-WS830

Polemount Bracket

BIT-WS2774/2779


Video

Dimension:




Unit: mm
