bit-cctv remote pan tilt webcam integrates full high definition picture quality, remote pan/tilt control and multi-protocol compatibility, providing plug-and-play video conference and security monitoring solutions for system integrators. bit-cctv are the source of production manufacturers, with independent research and development and production capacity, for bulk procurement customers to provide factory direct supply prices and shorter delivery cycle.
Image sensor
Optical variable magnification
Highest video format
Horizontal rotation angle
Vertical rotation angle
Number of preset positions
Video output interface
Signal-to-noise ratio
Control protocols
Built-in 2D and 3D digital noise reduction algorithms can still output clean, noise-free high-definition images in 0.5 Lux low-light environment, meeting the needs of all-weather monitoring and dark-l...
20x optical zoom lens with advanced autofocus algorithm can lock the focus in milliseconds, keeping the picture sharp and clear even when shooting from a distance.
supports up to 255 preset positions for storage, with a pan-tilt positioning accuracy of 0.1 degrees, which can quickly switch between multiple monitoring points, greatly improving the efficiency of i...
supports HDMI, USB 3.0, 3G-SDI and RJ45 network output at the same time, all interfaces can output 1080P60 video, and the delay is lower than the industry average.
UVC standard drive-free connection is realized through USB interface, compatible with mainstream software such as Zoom, Teams, WebEx, OBS, etc., and can be quickly deployed without additional driver i...
high-precision stepping motor and mute transmission mechanism are adopted, pan-tilt rotation noise is controlled within 25 decibels, and normal communication will not be interfered in quiet scenes suc...
| category | Parameters | Specification |
|---|---|---|
| Image sensor | Sensor type | 1/2.8-inch progressive scan CMOS |
| Effective pixels | 2.07 million | |
| Signal-to-noise ratio | 55 decibels | |
| Minimum Illumination | 0.5 Lux (F1.8, AGC enabled) | |
| lens | Optical zoom | 20 times |
| Numbers multiplied | 12 times | |
| focal length | f=5.2 to 98 mm | |
| aperture | F1.6 to F3.5 | |
| Horizontal field of view | 54.7 degrees (wide-angle) to 3.3 degrees (telephoto) | |
| Video format | Maximum resolution | 1080P60 |
| Video format | 1080P60/50/30/25, 1080I60/50, 720P60/50 | |
| Gimbal parameters | Horizontal rotation range | ±170 degrees |
| Vertical rotation range | -30 to 90 degrees | |
| Horizontal speed | 1.7 to 100 degrees/second | |
| Vertical rotation speed | 1.7 to 69.9 degrees/second | |
| Preset number of positions | 255 | |
| Preset position accuracy | 0.1 degrees | |
| interface | Video output | HDMI x1, 3G-SDI x1, USB 3.0 x1, RJ45 x1 |
| Audio input | 3.5 mm Linear Input | |
| Control Interface | RS-232 input/output, RS-485 | |
| Network function | Video compression | H.265 / H.264 / MJPEG |
| Network Protocol | TCP/IP, HTTP, RTSP, RTMP, ONVIF | |
| Dual stream | Supports main stream + sub-stream | |
| Control Protocol | Protocol support | VISCA, Pelco-D, Pelco-P |
| USB protocol | UVC 1.1 / UAC | |
| General parameters | Input voltage | DC 12V |
| Maximum power consumption | 12 watts | |
| Operating temperature | -10 to 40 degrees Celsius | |
| Storage temperature | -40 to 60 degrees Celsius | |
| Installation method | Desktop, wall, ceiling, tripod |
the coverage area of single bit-cctv remote pan tilt webcam can reach more than 5 times that of traditional fixed cameras. system integrators can complete the whole-field deployment without dead corne....
VISCA and Pelco full protocol remote control is supported. Integrators can remotely complete parameter configuration, preset position calibration and firmware upgrade through upper computer or central....
HDMI, SDI, USB and IP four independent outputs are supported at the same time, perfectly compatible with central control system, video conference terminal, push stream encoder and local recording and ....
suitable for integration teams undertaking projects such as enterprise conference rooms, education recording and broadcasting, command centers, etc. bit-cctv remote pan tilt webcam to provide standard...
it is suitable for engineering teams deploying remote monitoring in parks, office buildings, warehouses and other places. with 20 times optical magnification and 255 preset positions, a single device ...
It is suitable for the construction of smart classrooms in universities, vocational colleges and enterprise training centers. Remote pan-tilt control and automatic focusing function enable lecturers t...
it is suitable for hospital operation teaching, remote consultation and medical association collaboration scenes. it bit-cctv the full high definition image quality and low delay output of remote pan ...
Choose desktop placement, ceiling inversion, or wall side mounting according to the installation environment. Use the standard bracket to secure the camera firmly and ensure that there are no obstruct....
Connect a USB 3.0 cable between the camera and your computer. The system will automatically recognize it as a UVC video device. Open software such as Zoom, Teams, or OBS to directly access the screen..
Control the gimbal rotation and zoom through the infrared remote control. After adjusting the commonly used shooting angle, long press the number key to save the preset position, and then quickly call....
Use RS-232 serial cable to connect the camera and the central control host, send instructions through the VISCA protocol, and realize one-click scene switching and gimbal control on the control panel ....
.webp "Factory")
Support. This product complies with the UVC standard protocol. No drivers need to be installed after connecting to the computer via USB 3.0. The system automatically recognizes it as a video device an...
Up to 255 preset bits can be saved. Nine of them can be set directly via infrared remote control, and all 255 can be set via RS-232/RS-485 serial port or network protocol to meet the need for rapid sw...
Support. The camera is equipped with an RJ45 network interface, supports VISCA over IP protocol for remote gimbal control, and supports RTSP and RTMP protocols for network video streaming, which can b...
The camera has a minimum illumination of 0.5 Lux and, combined with 2D and 3D digital noise reduction technology, can still output clear, low-noise Full HD images in low-light or dusk indoor environme...
Yes. The camera supports four-way synchronous independent output of HDMI, 3G-SDI, USB 3.0 and RJ45. All interfaces can output 1080P video at the same time to meet the needs of field display, recording...
Compatible with almost all mainstream software, including Zoom, Microsoft Teams, WebEx, Google Meet, Skype, OBS Studio, YouTube Live, and vMix, it can be recognized and invoked by software via USB plu...
